Spectrum RAC2V1S 无线路由器完整bootlog

导出了该路由启动后的完整bootlog,供其他玩机的一起看看

BTRM
V1.6
CPU0
L1CD
MMUI
MMU7
DATA
ZBBS
MAIN
OTP?
OTPP
USBT
NAND
IMG?
IMGL
UHD?
UHDP
RLO?
RLOP
UBI?
UBIP
PASS
----
HELO
5.0203-1.0.38-161.184
CPU0
L1CD
MMUI
MMUA
CODE
ZBBS
MAIN
NVRAM memcfg 0x1427
MCB chksum 0xa89ec7d9, config 0x1427
MemsysInit lpf0_generic_aarch64 1.3.0.1 20150910
DDR3
900017E8 80018000 8001A000 00000000 00000000 0050371A
MCB rev=0x00040301 Ref ID=0x0371A Sub Bld=0x005
Dram Timing 11-11-11
DDR3-1600 CL11 total 512MB 1 16bits part[s] %1 SSC
Add/Ctl Alignment
no adjustment
ZQ Cal LP PHY
R in Ohm
P: Finger=0x2D0 Term=0x78 Drv=0x28
N: Finger=0x2D0 Term=0x78 Drv=0x2A
PLL Ref(Hz)=0x02FAF080 UI STEPS=0x038
DDR CLK(MHz)=0x31B WL CLK dly(ps)=0x0C8 bitT(ps)=0x274 VDLsize(fs)=0x2BCE CLK_VDL=0x01A
SHMOO 28nm
8001A000 80018800 00000000 00020000 00000000
Shmoo WL
One UI Steps : 0x43
auto-clk result = 00B (filter=0C steps)
initial CLK shift = 01A
final CLK shift = 00B
0000000000111111111122222222223333333333444444444455555555556666666
0123456789012345678901234567890123456789012345678901234567890123456
00 S-------------X++++++++++++++++++++++++++++++++++++++++++++++++++++
01 S------------X+++++++++++++++++++++++++++++++++++++++++++++++++++++
Shmoo RD En
FORCED WR ODT = 0x18001800
DQSN DRIVE PAD CONTROL (from) (to)
B0 00031A51 00079A51
B1 00031A51 00079A51
B0 RISE UI=1 VDL=11 PICK UI=2 VDL=11
B1 RISE UI=1 VDL=0E PICK UI=2 VDL=0E
0000000000111111111122222222223333333333444444444455555555556666666
0123456789012345678901234567890123456789012345678901234567890123456
00 --S--------------X+++++++++++++++++++++++++++++++++++++++++++++++++
01 --S-----------X++++++++++++++++++++++++++++++++++++++++++++++++++++
Shmoo RD DQ NP
DQS :
B0 VDL=3A ok
B1 VDL=38 ok
0000000000111111111122222222223333333333444444444455555555556666666
0123456789012345678901234567890123456789012345678901234567890123456
00 --+++++++++++++++++++++++X++++++++++++++++++++++++-----------------
01 -------+++++++++++++++++++++++X+++++++++++++++++++++++-------------
02 -+++++++++++++++++++++++X++++++++++++++++++++++++------------------
03 -------++++++++++++++++++++++++X++++++++++++++++++++++++-----------
04 ---+++++++++++++++++++++++X++++++++++++++++++++++++----------------
05 -------+++++++++++++++++++++++X++++++++++++++++++++++++------------
06 --+++++++++++++++++++++++X++++++++++++++++++++++++-----------------
07 ---------+++++++++++++++++++++++X++++++++++++++++++++++++----------
08 -----++++++++++++++++++++++++X++++++++++++++++++++++++-------------
09 --+++++++++++++++++++++++++X+++++++++++++++++++++++++--------------
10 ----++++++++++++++++++++++++X+++++++++++++++++++++++++-------------
11 -+++++++++++++++++++++++++X+++++++++++++++++++++++++---------------
12 ------+++++++++++++++++++++++++X++++++++++++++++++++++++++---------
13 --++++++++++++++++++++++++X+++++++++++++++++++++++++---------------
14 ----++++++++++++++++++++++++X+++++++++++++++++++++++++-------------
15 ----+++++++++++++++++++++++++X+++++++++++++++++++++++++------------
Shmoo RD DQ P
0000000000111111111122222222223333333333444444444455555555556666666
0123456789012345678901234567890123456789012345678901234567890123456
00 ++++++++++++++++++++++++X+++++++++++++++++++++++++-----------------
01 ------++++++++++++++++++++++++X++++++++++++++++++++++++------------
02 ++++++++++++++++++++++++X++++++++++++++++++++++++------------------
03 ------++++++++++++++++++++++++X+++++++++++++++++++++++++-----------
04 --++++++++++++++++++++++++X++++++++++++++++++++++++----------------
05 ------++++++++++++++++++++++++X++++++++++++++++++++++++------------
06 ++++++++++++++++++++++++X+++++++++++++++++++++++++-----------------
07 --------++++++++++++++++++++++++X++++++++++++++++++++++++----------
08 -----++++++++++++++++++++++++X++++++++++++++++++++++++-------------
09 --+++++++++++++++++++++++++X++++++++++++++++++++++++++-------------
10 ---+++++++++++++++++++++++++X+++++++++++++++++++++++++-------------
11 -+++++++++++++++++++++++++X++++++++++++++++++++++++++--------------
12 ------+++++++++++++++++++++++++X++++++++++++++++++++++++++---------
13 --+++++++++++++++++++++++++X+++++++++++++++++++++++++--------------
14 ---+++++++++++++++++++++++++X+++++++++++++++++++++++++-------------
15 ----+++++++++++++++++++++++++X+++++++++++++++++++++++++------------
Shmoo RD DQ N
0000000000111111111122222222223333333333444444444455555555556666666
0123456789012345678901234567890123456789012345678901234567890123456
00 -+++++++++++++++++++++++++X++++++++++++++++++++++++++--------------
01 --------++++++++++++++++++++++++X+++++++++++++++++++++++++---------
02 -+++++++++++++++++++++++++X+++++++++++++++++++++++++---------------
03 -------+++++++++++++++++++++++++X++++++++++++++++++++++++++--------
04 ---+++++++++++++++++++++++++X++++++++++++++++++++++++++------------
05 --------+++++++++++++++++++++++++X++++++++++++++++++++++++++-------
06 --+++++++++++++++++++++++++X++++++++++++++++++++++++++-------------
07 ---------++++++++++++++++++++++++++X++++++++++++++++++++++++++-----
08 -----++++++++++++++++++++++++X+++++++++++++++++++++++++------------
09 --+++++++++++++++++++++++++X+++++++++++++++++++++++++--------------
10 ---+++++++++++++++++++++++++X+++++++++++++++++++++++++-------------
11 -+++++++++++++++++++++++++X++++++++++++++++++++++++++--------------
12 ------+++++++++++++++++++++++++X++++++++++++++++++++++++++---------
13 --+++++++++++++++++++++++++X++++++++++++++++++++++++++-------------
14 ---+++++++++++++++++++++++++X++++++++++++++++++++++++++------------
15 ----++++++++++++++++++++++++++X++++++++++++++++++++++++++----------
RD DQS adjustments :
BL0: Start: 0x38 Final: 0x3A
BL1: Start: 0x38 Final: 0x38
Shmoo WR DQ
0000000000111111111122222222223333333333444444444455555555556666666
0123456789012345678901234567890123456789012345678901234567890123456
00 -++++++++++++++++++++++++X++++++++++++++++++++++++-----------------
01 ----++++++++++++++++++++++++X++++++++++++++++++++++++--------------
02 --++++++++++++++++++++++X+++++++++++++++++++++++-------------------
03 ------++++++++++++++++++++++++X+++++++++++++++++++++++++-----------
04 --+++++++++++++++++++++++++X+++++++++++++++++++++++++--------------
05 ------++++++++++++++++++++++++X+++++++++++++++++++++++++-----------
06 ++++++++++++++++++++++++X+++++++++++++++++++++++++-----------------
07 -------++++++++++++++++++++++++X+++++++++++++++++++++++++----------
08 ------+++++++++++++++++++++++X++++++++++++++++++++++++-------------
09 -----+++++++++++++++++++++++X++++++++++++++++++++++++--------------
10 ------+++++++++++++++++++++++X++++++++++++++++++++++++-------------
11 --++++++++++++++++++++++++X+++++++++++++++++++++++++---------------
12 ------++++++++++++++++++++++++X+++++++++++++++++++++++++-----------
13 ---++++++++++++++++++++++++X+++++++++++++++++++++++++--------------
14 ---+++++++++++++++++++++++++X+++++++++++++++++++++++++-------------
15 ----+++++++++++++++++++++++++X+++++++++++++++++++++++++------------
Shmoo WR DM
WR DM
0000000000111111111122222222223333333333444444444455555555556666666
0123456789012345678901234567890123456789012345678901234567890123456
00 -----+++++++++++++++++++++++++X+++++++++++++++++++++++++-----------
01 --++++++++++++++++++++++++X+++++++++++++++++++++++++---------------
DDR test done successfully
Version cfe-rom: 0.8.2
FPS0
J2EP
Base: 5.2_03
CFE version 1.0.38-161.184 for BCM94908 (64bit,SP,LE)
Build Date: vendredi 6 octobre 2017, 18:20:02 (UTC+0200) (g601671@rmm-1186759)
Copyright (C) 2000-2015 Broadcom Corporation.
Version cfe-ram: 0.8.2
Boot Strap Register: 0x6fd42
Chip ID: BCM4906_A0, Broadcom B53 Quad Core: 1800MHz
Total Memory: 536870912 bytes (512MB)
NAND ECC BCH-4, page size 0x800 bytes, spare size used 64 bytes
NAND flash device: Spansion S34ML02G1, id 0x01da block 128KB size 262144KB
pmc_init:PMC using DQM mode
pmc_init:7 0 fe790472 34c0346
Board IP address : 192.168.1.1:ffffff00
Host IP address : 192.168.1.100
Gateway IP address :
Run from flash/host/tftp (f/h/c) : f
Default host run file name : vmlinux
Default host flash file name : bcm963xx_fs_kernel
Boot delay (0-9 seconds) : 1
Default host ramdisk file name :
Default ramdisk store address :
Default DTB file name :
Board Id : F@ST5280
Number of MAC Addresses (1-64) : 10
Base MAC Address : 98:1e:19:5e:6a:f2
PSI Size (1-128) KBytes : 128
Enable Backup PSI [0|1] : 0
System Log Size (0-256) KBytes : 0
Auxillary File System Size Percent: 0
flow memory allocation (MB) : 14
buffer memory allocation (MB) : 16
DHD 0 memory allocation (MB) : 0
DHD 1 memory allocation (MB) : 0
DHD 2 memory allocation (MB) : 0
WLan Feature : 0x00
Partition 1 Size (MB) :
Partition 2 Size (MB) :
Partition 3 Size (MB) :
Partition 4 Size (MB) (Data) : 4MB
Initalizing switch low level hardware.
Software Resetting Switch ... Done.
Waiting MAC port Rx/Tx to be enabled by hardware ...Done
Disable Switch All MAC port Rx/Tx
Initializing UBI and starting U-Boot...
Looking for UBI...
Looking for U-Boot...
Found valid GSDF
Starting U-Boot from UBI at 0x0000000000080000
U-Boot 2017.05@sc-0.14.2 (Oct 06 2017 - 18:00:03 +0200) sc_f5280
CPU: BCM490x
Model: Sagemcom F@ST5280
DRAM: 512 MiB
NAND: 256 MiB
MMC:
ubi0: attaching mtd1
ubi0: scanning is finished
ubi0: attached mtd1 (name "mtd=2", size 8 MiB)
ubi0: PEB size: 131072 bytes (128 KiB), LEB size: 126976 bytes
ubi0: min./max. I/O unit sizes: 2048/2048, sub-page size 2048
ubi0: VID header offset: 2048 (aligned 2048), data offset: 4096
ubi0: good PEBs: 70, bad PEBs: 0, corrupted PEBs: 0
ubi0: user volume: 4, internal volumes: 1, max. volumes count: 128
ubi0: max/mean erase counter: 128/7, WL threshold: 4096, image sequence number: 49925173
ubi0: available PEBs: 0, total reserved PEBs: 70, PEBs reserved for bad PEB handling: 30
Volume bootenv not found!
** Unable to read env from boot:bootenv **
Using default environment
In: serial
Out: serial
Err: serial
Version: 2017.05@sc-0.14.2
Board: F@ST5280
Mode: standard
ubi0: detaching mtd1
ubi0: mtd1 is detached
ubi0: attaching mtd1
ubi0: scanning is finished
ubi0: attached mtd1 (name "mtd=2", size 8 MiB)
ubi0: PEB size: 131072 bytes (128 KiB), LEB size: 126976 bytes
ubi0: min./max. I/O unit sizes: 2048/2048, sub-page size 2048
ubi0: VID header offset: 2048 (aligned 2048), data offset: 4096
ubi0: good PEBs: 70, bad PEBs: 0, corrupted PEBs: 0
ubi0: user volume: 4, internal volumes: 1, max. volumes count: 128
ubi0: max/mean erase counter: 128/7, WL threshold: 4096, image sequence number: 49925173
ubi0: available PEBs: 0, total reserved PEBs: 70, PEBs reserved for bad PEB handling: 30
Net: brcmenet
Autoboot in 0 seconds. Press <SPACE> to abort.
sbp: check net command
sbp: boot operational
sb3: booting 'operational'
ubi0: detaching mtd1
ubi0: mtd1 is detached
ubi0: attaching mtd1
ubi0: scanning is finished
ubi0: attached mtd1 (name "mtd=3", size 191 MiB)
ubi0: PEB size: 131072 bytes (128 KiB), LEB size: 126976 bytes
ubi0: min./max. I/O unit sizes: 2048/2048, sub-page size 2048
ubi0: VID header offset: 2048 (aligned 2048), data offset: 4096
ubi0: good PEBs: 1530, bad PEBs: 0, corrupted PEBs: 0
ubi0: user volume: 3, internal volumes: 1, max. volumes count: 128
ubi0: max/mean erase counter: 422/5, WL threshold: 4096, image sequence number: 1077548300
ubi0: available PEBs: 536, total reserved PEBs: 994, PEBs reserved for bad PEB handling: 40
sb3: loaded image 'operational' (27683584 bytes) at 0x0000000001000000
sb3: image 'operational' type is 'gsdf'
sb3: image 'operational' signature is OK
sb3: no pre-boot command found
sb3: found FDT in image 'operational'
## Booting kernel from Legacy Image at 0101f000 ...
Image Name: scOS SGAC11003K (8c.27.43.624_pr
Image Type: AArch64 Linux Kernel Image (gzip compressed)
Data Size: 3342336 Bytes = 3.2 MiB
Load Address: 00080000
Entry Point: 00080000
Verifying Checksum ... OK
## Flattened Device Tree blob at 02a66000
Booting using the fdt blob at 0x2a66000
Uncompressing Kernel Image ... OK
reserving fdt memory region: addr=0 size=10000
Loading Device Tree to 000000000fffc000, end 000000000ffffaf7 ... OK
Starting kernel ...
Booting Linux on physical CPU 0x0
Linux version 4.1.27 (g507801@compil-atr-1) (gcc version 5.3.0 (GCC) ) #6 SMP PREEMPT Mon Mar 5 18:46:16 CET 2018
CPU: AArch64 Processor [420f1000] revision 0
Detected VIPT I-cache on CPU0
alternatives: enabling workaround for ARM erratum 845719
On node 0 totalpages: 127488
DMA zone: 1792 pages used for memmap
DMA zone: 0 pages reserved
DMA zone: 127488 pages, LIFO batch:31
PERCPU: Embedded 16 pages/cpu @ffffffc01ffb4000 s25536 r8192 d31808 u65536
pcpu-alloc: s25536 r8192 d31808 u65536 alloc=16*4096
pcpu-alloc: [0] 0 [0] 1 [0] 2 [0] 3
Built 1 zonelists in Zone order, mobility grouping on. Total pages: 125696
Kernel command line: root=mtd:rootfs earlyprintk debug init=/etc/preinit ro rootfstype=squashfs console=ttyS0,115200 rootfs_offset=0x364000 rootfs_size=0x1702000 coherent_pool=1M init=/etc/preinit rw mtdparts=brcmnand.0:128k(nvram),640k(cfe),8960k(boot),195840k(ubi),-(data) ubi.mtd=ubi,0 part_main=ubi part_boot=boot image_ubivol=operational board_type=00030080
UBI image volume: "operational"
log_buf_len individual max cpu contribution: 4096 bytes
log_buf_len total cpu_extra contributions: 12288 bytes
log_buf_len min size: 16384 bytes
log_buf_len: 32768 bytes
early log buf free: 14892(90%)
PID hash table entries: 2048 (order: 2, 16384 bytes)
Dentry cache hash table entries: 65536 (order: 7, 524288 bytes)
Inode-cache hash table entries: 32768 (order: 6, 262144 bytes)
Memory: 454456K/509952K available (4683K kernel code, 277K rwdata, 1588K rodata, 224K init, 397K bss, 55496K reserved, 0K cma-reserved)
Virtual kernel memory layout:
vmalloc : 0xffffff8000000000 - 0xffffffbdffff0000 ( 247 GB)
vmemmap : 0xffffffbe00000000 - 0xffffffbfc0000000 ( 7 GB maximum)
0xffffffbe00000000 - 0xffffffbe00700000 ( 7 MB actual)
fixed : 0xffffffbffabfd000 - 0xffffffbffac00000 ( 12 KB)
PCI I/O : 0xffffffbffae00000 - 0xffffffbffbe00000 ( 16 MB)
modules : 0xffffffbffc000000 - 0xffffffc000000000 ( 64 MB)
memory : 0xffffffc000000000 - 0xffffffc020000000 ( 512 MB)
.init : 0xffffffc0006a1000 - 0xffffffc0006d9000 ( 224 KB)
.text : 0xffffffc000080000 - 0xffffffc0006a0624 ( 6274 KB)
.data : 0xffffffc0006da000 - 0xffffffc00071f620 ( 278 KB)
Preemptible hierarchical RCU implementation.
NR_IRQS:64 nr_irqs:64 0
Architected cp15 timer(s) running at 50.00MHz (phys).
clocksource arch_sys_counter: mask: 0xffffffffffffff max_cycles: 0xb8812736b, max_idle_ns: 440795202655 ns
sched_clock: 56 bits at 50MHz, resolution 20ns, wraps every 4398046511100ns
BRCM Legacy Drivers' Helper, all legacy drivers' IO memories/interrupts should be remapped here
Remapping interrupts...
hwirq virq
61 5
64 6
66 7
91 8
92 9
93 10
77 11
78 12
79 13
80 14
81 15
82 16
83 17
84 18
85 19
86 20
88 21
96 22
97 23
98 24
99 25
118 26
119 27
106 28
104 29
105 30
76 31
120 32
110 33
148 34
154 35
155 36
156 37
157 38
158 39
159 40
69 41
Remapping IO memories...
phys virt size
00000000ff800000 ffffff8000008000 00003000
00000000ff858000 ffffff8000002000 00001000
00000000ff85a000 ffffff800000c000 00001000
00000000ffe00000 ffffff8000040000 00020000
0000000080002000 ffffff800000e000 00001000
0000000080018000 ffffff8000010000 00004000
0000000080200000 ffffff8000018000 00005000
0000000080280000 ffffff8000016000 00001000
0000000082200000 ffffff8000080000 00100000
0000000080080000 ffffff8000200000 00050000
0000000080008000 ffffff8000020000 00003fff
000000008000c000 ffffff8000028000 00003fff
0000000081060000 ffffff8000030000 00004000
0000000080100000 ffffff8000038000 00002000
0000000080010000 ffffff800001e000 00001000
000000008001d000 ffffff800003c000 00001010
000000008001c000 ffffff8000026000 00000448
console [ttyS0] enabled
Calibrating delay loop (skipped), value calculated using timer frequency.. 100.00 BogoMIPS (lpj=500000)
pid_max: default: 32768 minimum: 301
Mount-cache hash table entries: 1024 (order: 1, 8192 bytes)
Mountpoint-cache hash table entries: 1024 (order: 1, 8192 bytes)
--Kernel Config--
SMP=1
PREEMPT=1
DEBUG_SPINLOCK=0
DEBUG_MUTEXES=0
Broadcom Logger v0.1
Do not need to create mapping for reserved memory phys 0x07000000 size 0x02000000 for buffer
creating mapping for reserved memory phys 0x06200000 virt 0xffffffc006200000 size 0x00e00000 for flow
pmc_init:PMC using DQM mode
CPU1: Booted secondary processor
Detected VIPT I-cache on CPU1
CPU2: failed to come online
CPU3: failed to come online
Brought up 2 CPUs
SMP: Total of 2 processors activated.
CPU: All CPU(s) started at EL2
alternatives: patching kernel code
clocksource jiffies: mask: 0xffffffff max_cycles: 0xffffffff, max_idle_ns: 19112604462750000 ns
NET: Registered protocol family 16
cpuidle: using governor ladder
cpuidle: using governor menu
vdso: 2 pages (1 code @ ffffffc0006e1000, 1 data @ ffffffc0006e0000)
DMA: preallocated 1024 KiB pool for atomic allocations
ACPI: Interpreter disabled.
SCSI subsystem initialized
usbcore: registered new interface driver usbfs
usbcore: registered new interface driver hub
usbcore: registered new device driver usb
bcmhs_spi bcmhs_spi.1: master is unqueued, this is deprecated
skbFreeTask created successfully
gbpm_do_work scheduled
BLOG v3.0 Initialized
BLOG Rule v1.0 Initialized
Broadcom IQoS v0.1 initialized
Broadcom GBPM v0.1 initialized
Switched to clocksource arch_sys_counter
pnp: PnP ACPI: disabled
NET: Registered protocol family 2
TCP established hash table entries: 4096 (order: 3, 32768 bytes)
TCP bind hash table entries: 4096 (order: 4, 65536 bytes)
TCP: Hash tables configured (established 4096 bind 4096)
UDP hash table entries: 256 (order: 1, 8192 bytes)
UDP-Lite hash table entries: 256 (order: 1, 8192 bytes)
NET: Registered protocol family 1
PCI: CLS 0 bytes, default 64
futex hash table entries: 1024 (order: 4, 65536 bytes)
squashfs: version 4.0 (2009/01/31) Phillip Lougher
jffs2: version 2.2. (NAND) (SUMMARY) © 2001-2006 Red Hat, Inc.
fuse init (API version 7.23)
io scheduler noop registered (default)
brd: module loaded
loop: module loaded
nand: Could not find valid ONFI parameter page; aborting
nand: device found, Manufacturer ID: 0x01, Chip ID: 0xda
nand: AMD/Spansion NAND 256MiB 3,3V 8-bit
nand: 256 MiB, SLC, erase size: 128 KiB, page size: 2048, OOB size: 64
bcm63xx_nand ff801800.nand: Adjust timing_1 to 0x65324458 timing_2 to 0x80040e54
bcm63xx_nand ff801800.nand: detected 256MiB total, 128KiB blocks, 2KiB pages, 16B OOB, 8-bit, BCH-4
Bad block table found at page 131008, version 0x01
Bad block table found at page 130944, version 0x01
Part[0] name=rootfs, size=20000, ofs=0
Part[1] name=rootfs_update, size=a0000, ofs=20000
Part[2] name=ubi, size=7a40000, ofs=c0000
Part[3] name=data, size=0, ofs=0
Part[4] name=nvram, size=0, ofs=0
ELB
5 cmdlinepart partitions found on MTD device brcmnand.0
Creating 5 MTD partitions on "brcmnand.0":
0x000000000000-0x000000020000 : "nvram"
0x000000020000-0x0000000c0000 : "cfe"
0x0000000c0000-0x000000980000 : "boot"
0x000000980000-0x00000c8c0000 : "ubi"
0x00000c8c0000-0x000010000000 : "data"
tun: Universal TUN/TAP device driver, 1.6
tun: (C) 1999-2004 Max Krasnyansky <maxk@qualcomm.com>
PPP generic driver version 2.4.2
PPP BSD Compression module registered
PPP Deflate Compression module registered
NET: Registered protocol family 24
i2c /dev entries driver
bcm96xxx-wdt ff800428.watchdog: Broadcom BCM96xxx watchdog timer
brcmboard registered
brcmboard: brcm_board_init entry
print_rst_status: Last RESET due to SW reset
print_rst_status: RESET reason: 0x00000000
SES: LED GPIO 0x400c is enabled
DYING GASP IRQ Initialized and Enabled
map_hw_timer_interrupt,132: interrupt_id 22
map_hw_timer_interrupt,132: interrupt_id 23
map_hw_timer_interrupt,132: interrupt_id 24
map_hw_timer_interrupt,132: interrupt_id 25
Serial: BCM63XX driver $Revision: 3.00 $
Magic SysRq with Auxilliary trigger char enabled (type ^ h for list of supported commands)
ttyS0 at MMIO 0xff800640 (irq = 6, base_baud = 921600) is a BCM63XX
BPM: tot_mem_size=536870912B (512MB), buf_mem_size <15%> =80530635B (76MB), num of buffers=35951, buf size=2240
Broadcom BPM Module Char Driver v0.1 Registered<3004>
PCIe HCD (impl1)
bcm963xx-pcie: found core [0] Rev [ 3. 4]
bcm963xx-pcie: failed to bring up core [0] link
bcm963xx-pcie: found core [1] Rev [ 3. 4]
bcm963xx-pcie: [1] Link Speed set to 1
bcm963xx-pcie: failed to bring up core [1] link
bcm963xx-pcie: found core [2] Rev [ 3. 4]
bcm963xx-pcie: failed to bring up core [2] link
GACT probability NOT on
Mirror/redirect action on
u32 classifier
input device check on
Actions configured
Initializing XFRM netlink socket
NET: Registered protocol family 10
sit: IPv6 over IPv4 tunneling driver
NET: Registered protocol family 17
NET: Registered protocol family 15
bridge: automatic filtering via arp/ip/ip6tables has been deprecated. Update your scripts to load br_netfilter if you need this.
L2TP core: blog_l2tp_rcv_check
l2tp_core: L2TP core driver, V2.0
l2tp_ppp: PPPoL2TP kernel driver, V2.0
8021q: 802.1Q VLAN Support v1.8
ubi0: attaching mtd3
ubi0: scanning is finished
ubi0: attached mtd3 (name "ubi", size 191 MiB)
ubi0: PEB size: 131072 bytes (128 KiB), LEB size: 126976 bytes
ubi0: min./max. I/O unit sizes: 2048/2048, sub-page size 2048
ubi0: VID header offset: 2048 (aligned 2048), data offset: 4096
ubi0: good PEBs: 1530, bad PEBs: 0, corrupted PEBs: 0
ubi0: user volume: 3, internal volumes: 1, max. volumes count: 128
ubi0: max/mean erase counter: 422/5, WL threshold: 4096, image sequence number: 1077548300
ubi0: available PEBs: 546, total reserved PEBs: 984, PEBs reserved for bad PEB handling: 30
ubi0: background thread "ubi_bgt0d" started, PID 352
Add partitions for UBI volume 'filesystem1'
Add partitions for UBI volume 'rescue'
Add partitions for UBI volume 'operational'
Creating 3 MTD partitions on "operational":
0x000000000000-0x00000001f000 : "firm_header"
0x00000001f000-0x000000383000 : "kernel"
0x000000364000-0x000001a66000 : "rootfs"
VFS: Mounted root (squashfs filesystem) readonly on device 31:10.
Freeing unused kernel memory: 224K (ffffffc0006a1000 - ffffffc0006d9000)
kernel.hotplug = /sbin/mdev
- preinit -
- regular preinit -
- init -
UBIFS (ubi0:0): background thread "ubifs_bgt0_0" started, PID 409
UBIFS (ubi0:0): recovery needed
UBIFS (ubi0:0): recovery completed
UBIFS (ubi0:0): UBIFS: mounted UBI device 0, volume 0, name "filesystem1"
UBIFS (ubi0:0): LEB size: 126976 bytes (124 KiB), min./max. I/O unit sizes: 2048 bytes/2048 bytes
UBIFS (ubi0:0): FS size: 31236096 bytes (29 MiB, 246 LEBs), journal size 1523712 bytes (1 MiB, 12 LEBs)
UBIFS (ubi0:0): reserved for root: 1475357 bytes (1440 KiB)
UBIFS (ubi0:0): media format: w4/r0 (latest is w4/r0), UUID 9A40B41F-DB01-498D-8C74-68BBD8C6499C, small LPT model
ubi1: attaching mtd2
ubi1: scanning is finished
ubi1: attached mtd2 (name "boot", size 8 MiB)
ubi1: PEB size: 131072 bytes (128 KiB), LEB size: 126976 bytes
ubi1: min./max. I/O unit sizes: 2048/2048, sub-page size 2048
ubi1: VID header offset: 2048 (aligned 2048), data offset: 4096
ubi1: good PEBs: 70, bad PEBs: 0, corrupted PEBs: 0
ubi1: user volume: 4, internal volumes: 1, max. volumes count: 128
ubi1: max/mean erase counter: 128/7, WL threshold: 4096, image sequence number: 49925173
ubi1: available PEBs: 26, total reserved PEBs: 44, PEBs reserved for bad PEB handling: 4
ubi1: background thread "ubi_bgt1d" started, PID 519
Add partitions for UBI volume 'secondaryboot'
Add partitions for UBI volume 'uboot'
Add partitions for UBI volume 'uboot-rescue'
Add partitions for UBI volume 'permanent_param'
BUG: scheduling while atomic: insmod/743/0x00000003
Call trace:
hub 1-0:1.0: config failed, hub doesn't have any ports! (err -19)

当前在原版CFE的条件下,接了TTL也就能做这点有用的事.

赞(0) 打赏
版权声明:本文采用知识共享 署名4.0国际许可协议 [BY-NC-SA] 进行授权
文章名称:《Spectrum RAC2V1S 无线路由器完整bootlog》
文章链接:https://www.bigxd.com/2021/04/961.html
本站资源仅供个人学习交流,请于下载后24小时内删除,不允许用于商业用途,否则法律问题自行承担。

评论 抢沙发

评论前必须登录!



觉得文章有用就打赏一下文章作者

微信扫一扫打赏
